Features
1.Gantry rack double drive system, reinforced welding body. The stress is eliminated by tempering and vibration aging to ensure that the machine deformation tolerance is within 0.02 mm；
2.Crossbeam are made through drawing and finishing process: Lightweight, high rigidity, high dynamic performance；
3.Cutting head has the leapfrog function, parabolic motion between the cutting contours. Automatic frog jump during switching contours, high cutting efficiency；
4.Automatic concentrated lubrication function, automatic lubrication for traditional parts by system control. No manual intervention is needed so as to ensure the accuracy and service life of the moving part.
Technical Parameter
| Model | CMA2040C-G-A | CMA1540C-G-A | CMA1530C-G-E |
| Laser power (W) | 700-2000 | 500-1500 | |
| Working area (mm) | 2000*4000 | 1500*4000 | 3000*1500 |
| Overall dimension (mm) | 6400*2700*2000 | 6400*2200*2000 | 5400*2200*2000 |
| Weight (kg) | 4800 | 4500 | 4000 |
| Positioning accuracy (mm) | ±0.03/1000 | ||
| Repeated positioning accuracy (mm) | ±0.02/1000 | ||
| Maximum speed (m/mim) | 60 | ||
| Maximum accelerated speed (m/min) | 0.8 | ||
| Supply voltage | Three phase 380V/50Hz/60Hz | ||
| Working environment | Temp: 5-40℃, Humidity:5-85% | ||
